Glass filled Nylon has proved to be an excellent choice for bearing and bushing application.
Glass filled Nylon has proved to be an excellent choice for bearing and bushing application. Its high compression modulus owing to the glass fibre reinforcement and excellent dimensional stability is very important in its functioning. GF-polyamides have high load-bearing capacity which makes them a good choice for back-up rings and guide ring applications. It has a good temperature and wear resistance as well.
* Nylon is Registered trademark of E.I. du Pont de Nemours and Company.
| Compound No. | Material | Material | Colour | Features | Major Application |
|---|---|---|---|---|---|
| PA01 | PG6040 | 40% Glass Fibre Filled Polyamide | Black | General Purpose | Light & Heavy duty wear rings |
| PA02 | PG6030 | 30% Glass Fibre Filled Polyamide | Black | General Purpose | Light duty wear rings |
| PA04 | PA6000 | Heat Stabilized Polyamide 6 with Moly | Grey | General Purpose | Back-ups, Anti extrusion ring |
| PA05 | PA6600 | Heat Stabilized Polyamide 6'6 | Natural | High Temp. Resistance | Back-ups for Rod Seals |
| PA06 | PA6600 | Heat Stabilized Polyamide 6'6 | Yellow | High Temp. Resistance | Anti extrusion ring in PS056 |
| PA09 | PG6040M | 40% Glass Fibre Filled Polyamide with Moly | Black | Low Friction, Good Mechanical Propert es | Seal Ring PS184 |
| PA10 | PG6040T | 40% Glass Fibre Filled Polyamide with Moly / PTFE | Black | Low Friction, Good Mechanical Propert es | Light & Heavy duty wear rings |
| PA15 | PA6600 | Heat Stabilized Polyamide 6'6 | Black | High Temp. Resistance | Back-ups in PS032 |
| PA22 | PG6010 | 10% Glass Fibre Filled Polyamide 6 | Orange | Self-lubricating,low coefficient of friction | AE Rings in Rs027 |
